Camera
|
|
Image sensor
|
1/4 type MOS sensor
|
|
Effective pixels
|
Approx. 1.3 megapixels
|
|
Scanning area
|
3.60 mm (H) x 2.70 mm (V)
{5/32 inches (H) x 11/100 inches (V)}
|
|
Scanning system
|
Progressive
|
|
Minimum illumination
|
Color : 1.5 lx, BW : 1.0 lx
|
|
Wide dynamic range
|
On/Off
|
|
Adaptive black stretch
|
On/Off
|
|
Back light compensation
|
On/Off
|
|
Light control mode setting
|
Indoor scene (50 Hz/60 Hz) / ELC
|
|
Maximum exposure time
|
1/30, 3/100, 3/120, 2/100, 2/120, 1/100, 1/120, 1/250,1/500, 1/1000, 1/2000, 1/4000, 1/10000
|
|
Gain (AGC)
|
On(Low)/ On(Mid)/ On(High)/ Off
|
|
Day & Night (electrical)
|
Off/Auto
|
|
White balance
|
ATW1/ ATW2/ AWC
|
|
Digital noise reduction
|
High/Low
|
|
Personal ID (OSD)
|
Up to 50 alphanumeric characters
|
|
Lens
|
|
Focal length
|
0.82 mm
|
|
Maximum aperture ratio
|
1 : 2.6
|
|
Angular field of view
|
Horizontal : 180°, Vertical : 140°
|
|
Recording
|
|
Resolution
|
Aspect ratio : 4:3
H.264 1280 x 960
JPEG 640 x 480 (Only HTML on PC, 5 fps)
|
|
Image compression method
|
H.264
Video bit rate :2048 kbps/ 4096 kbps/ 8192 kbps
Frame rate : 15 fps/ 30 fps
|
|
Audio compression method
|
G.726 (ADPCM) 32 kbps
|
|
Recording duration
|
Auto/Continue/10min/15min/20min/30min/60min/90min
|
|
Pre recording duration
|
Off/15s/30s
|
|
Overwrite
|
On/Off
|
|
Audio
|
On1(not mute during pre recording)
/On2(mute during pre recording)/Off
|
|
Compatible SDHC memory
card (option)
|
Manufactured by Panasonic SDHC memory card :
32 GB, Class 10
|
|
Network
|
|
Network IF
|
10BASE-T/100BASE-TX
|
|
Protocol *1
|
IPv6 : HTTP, FTP IPv4 : HTTP, FTP, DHCP
|
|
OS *2 *3
|
Microsoft Windows 7/Microsoft Windows Vista/ Microsoft Windows XP SP3
|
|
Browser
|
Windows Internet Explorer 9.0 (32-bit)
Windows Internet Explorer 8.0 (32-bit)
Windows Internet Explorer 7.0 (32-bit)
Microsoft Internet Explorer 6.0 SP3
|
|
Maximum concurrent access number
|
UP to 10 at JPEG, UP to 4 at H.264
|
|
Basic
|
|
Power source
|
12 V DC, PoE (IEEE802.3af compliant)
|
|
Power consumption
|
12 V DC*: 650 mA, PoE : 220mA 11 W (Class 0 device)
* ONLY CONNECT 12 V DC CLASS 2 POWER SUPPLY or LIMITED POWER SOURCE.
|
|
Ambient operating temperature
|
-10 °C to +50 °C {14 °F to 122 °F}
While worn on body : -10 °C to +45 °C {14 °F to 113 °F}
|
|
Ambient operating humidity
|
Less than 90 % (no condensation)
|
|
Continuous operating time
|
About 5 hours
(at normal temperature, at the time of purchase when charged fully)
|
|
Battery
|
WV-TB311 (Lithium-ion battery) only
|
|
Dimensions
|
45 mm (W) x 75 mm (H) x 41 mm (D)
{1-25/32 inches (W) x 2-15/16 inches (H) x 1-5/8 inches (D)}
(Excluding the cable and projection.)
|
|
Mass
|
WV-TW310L : Approx. 210 g {0.46 lbs.}
WV-TW310S : Approx. 160 g {0.35 lbs.}
|
|
Cable Length
|
WV-TW310L : 950 mm {37-3/8 inches}
WV-TW310S : 600 mm {23-5/8 inches}
|
|
Finish
|
Black
|
