Camera
|
|
Image Sensor
|
1/3 type MOS Sensor
|
|
Effective Pixels
|
Approx. 3.1 megapixels
|
|
Scanning Mode
|
Progressive scan
|
|
Scanning Area
|
4.51 mm(H) x 3.38 mm(V) {3/16 inches (H) x 1/8 inches (V)}
|
|
Minimum Illumination
|
Color: 1.2 lx, BW: 0.9 lx (F2.2, Auto slow shutter: Off (1/30s), Gain:On(High)}
Color: 0.075 lx, BW 0.056 lx (F2.2, Auto slow shutter: Max. 16/30s, Gain:On(High)) *1
|
|
White Balance
|
AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K)
|
|
Light Control Mode
|
Outdoor scene: Automatic integration
Indoor scene [50 Hz]: Automatic integration (up to 1/100 s)
Indoor scene [60 Hz]: Automatic integration (up to 1/120 s)
ELC: (up to 1/10,000 sec.)
|
|
Shutter Speed
|
Max shutter: 1/30, 3/100, 3/120, 2/100, 2/120, 1/100, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000(only at Super Dynamic OFF)
|
|
Super Dynamic
|
ON / OFF
|
|
Face Super Dynamic
|
ON / OFF (Only at Super Dynamic: ON)
|
|
Adaptive Black Stretch
|
ON / OFF (Only at Super Dynamic: OFF)
|
|
Fog compensation
|
ON / OFF
|
|
AGC
|
ON (LOW, MID, HIGH) / OFF
|
|
Electronic Sensitivity UP
|
OFF / Max. 2x (2/30 s), 4x (4/30 s), 6x (6/30 s), 10x (10/30 s), 16x (16/30 s)
|
|
Day & Night (electrical)
|
OFF / Auto
|
|
Digital Noise Reduction
|
High / Low
|
|
Video Motion Detection
|
ON / OFF, 4 areas available
|
|
Privacy Zone
|
ON / OFF (up to 2 zones available)
|
|
VIQS
|
ON / OFF (up to 2 zones available)
|
|
Camera Title (OSD)
|
Up to 20 characters (alphanumeric characters, marks), ON / OFF
|
|
Mirror Upside down
|
ON / OFF
|
|
Lens Distortion Conpensation
|
256 steps
|
|
Lens
|
|
Focal Length
|
1.95 mm
|
|
Zoom Ratio
|
1x / Extra Zoom 3x (2 megapixels at 640 x 360 resolution)
|
|
Angular Field of View
|
Horizontal: 100° Vertical: 81° (3 megapixels [4:3])
Horizontal: 95° Vertical: 62° (2/1.3 megapixels [16:9])
Horizontal: 84° Vertical: 68° (1.3 megapixels [4:3])
|
|
Maximum Aperture Ratio
|
1 : 2.2
|
|
Focusing Range
|
0.5 m ~ ∞
|
|
Aperture Range
|
F2.2
|
|
Adjusting Angle
|
|
Adjusting Angle
|
|
|
Browser GUI
|
|
Camera Control
|
Brightness
|
|
Display Mode
|
Spot, Quad: Image from 16 cameras can be displayed in 4 different Quad screens or 16 split screen (JPEG only). 20 characters camera title available.
|
|
Digital Zoom
|
1x, 2x, 4x controlled by browser GUI
|
|
Camera Title
|
Up to 20 alphanumeric characters
|
|
Clock Display
|
Time: 12H/24H, Date: 5 formats on the browser, Summer time (Manual)
|
|
Alarm Control
|
Reset
|
|
One Shot Capture
|
A still picture will be displayed on a newly opened window.
|
|
Audio
|
Mic Input: ON / OFF Volume adjustment: Low / Middle / High,
|
|
SD Memory Data Download
|
Still or motion Images recorded in the SDXC/SDHC/SD memory card can be downloaded.
|
|
GUI/Setup Menu Language
|
English, Italian, French, German, Spanish, Russian, Chinese, Japanese
|
|
System Log
|
Up to 100 (Internal)
Up to 4,000 (SDXC/SDHC/SD memory when the recording
format is set to JPEG.) error logs
|
|
Supported OS *2 *3
|
Microsoft® Windows® 8, Microsoft® Windows® 7,
Microsoft® Windows Vista®,Microsoft® Windows® XP SP3
|
|
Supported Browser
|
Windows® Internet Explorer® 10.0 (32 bit), Windows® Internet Explorer® 9.0 (32 bit),
Windows® Internet Explorer® 8.0 (32 bit),Windows® Internet Explorer® 7.0 (32 bit)
|
|
Network
|
|
Network IF
|
10Base-T / 100Base-TX, RJ-45 connector
|
|
Image Resolution
|
|
Image Capture Mode:
2 mega pixel [16:9]
|
H.264: 1,920 x 1,080 / 640 x 360 / 320 x 180, up to 30 fps
JPEG (MJPEG): 1,920 x 1,080 / 640 x 360 / 320 x 180, up to 30 fps
|
|
Image Capture Mode:
1.3 mega pixel [16:9]
|
H.264: 1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps
JPEG (MJPEG): 1,280 x 720 / 640 x 360 / 320 x 180, up to 30 fps
|
|
Image Capture Mode:
1.3 mega pixel [4:3]
|
H.264: 1,280 x 960 / VGA(640 x 480) / QVGA(320 x 240), up to 30 fps
JPEG (MJPEG): 1,280 x 960 / VGA(640 x 480) / QVGA(320 x 240), up to 30 fps
|
|
Image Capture Mode:
3 mega pixel [4:3]
|
H.264: 1,280 x 960, up to 15 fps
JPEG (MJPEG): 2,048 x1,536, up to 15 fps
|
|
H.264 *4
|
|
Transmission Mode
|
Constant bitrate / Frame rate priority / Best effort /Advanced VBR
|
|
Frame Rate
|
1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 fps
|
|
Bit Rate/Client
|
Constant bit rate/Best effort: 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 / 4,096 / 6,144 / 8,192 / 10,240 / 12,288 / 14,336 kbps
|
|
Image Quality
|
LOW / NORMAL / FINE
|
|
Refresh Interval
|
0.2 / 0.25 / 0.33 / 0.5 / 1 / 2 / 3 / 4 / 5 s
|
|
Transmission Type
|
UNICAST / MULTICAST
|
|
JPEG
|
|
Image Quality
|
10 steps
|
|
Refresh Interval
|
0.1 fps ~ 30 fps
|
|
Transmission Type
|
PULL / PUSH
|
|
Cropping
|
2 megapixels [16:9]
H.264 640×360/ 320×180, Max. 30 fps
MJPEG 640×360/ 320×180, Max. 30 fps
1.3 megapixels [16:9]
H.264 640×360/ 320×180, Max. 30 fps
MJPEG 640×360/ 320×180, Max. 30 fps
1.3 megapixels [4:3]
H.264 VGA (640×480)/ QVGA (320×240), Max. 30 fps
MJPEG VGA (640×480)/ QVGA (320×240), Max. 30 fps
|
|
Audio Compression
|
G.726 (ADPCM) 32 kbps / 16 kbps, G.711 64 kbps for transmitting, AAC for audio recording and sound detection
|
|
Audio Mode
|
OFF / Mic input
|
|
Authentication for Audio
|
Level 1 only / Level 2 higher / All users
|
|
Total Bit Rate
|
64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited
|
|
Supported Protocol
|
IPv6:
TCP/IP, UDP/IP, HTTP, HTTPS, RTP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6, MLD, ICMP, ARP
IPv4:
TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP,FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP
|
|
FTP Client
|
Alarm image transmission, FTP periodic transmission
(When the FTP transmission is failed, backup on an optional SDXC/SDHC/SD memory card is available. )
|
|
No. of Simultaneous Users
|
Up to 14 users (Depends on network conditions)
|
|
SDXC/SDHC/SD
Memory Card (Option)
|
H.264 recording (Audio recording is enable):
Manual REC / Alarm REC (Pre/Post) / Schedule REC
JPEG recording:
Manual REC / Alarm REC (Pre/Post) / Backup upon network failure Compatible
SD (SDHC/SDXC) card: Panasonic 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64GB** model
*SDHC card, ** SDXC card (except miniSD card and microSD card)
|
|
Cellular Phone Compatibility
|
JPEG image
|
|
Mobile Terminal Compatibility
|
iPad, iPhone, iPod touch (iOS 4.2.1 or later), Android™ mobile terminals
|
|
Alarm
|
|
Alarm Source
|
VMD, Command alarm, Sound detection
|
|
Alarm Actions
|
SDXC/SDHC/SD memory recording, E-mail noti cation, Indication on browser, FTP image transfer, Panasonic protocol output
|
|
Alarm Log
|
With SDXC/SDHC/SD memory card: 5,000 logs, without SDXC/SDHC/SD memory card: 1,000 logs
|
|
Schedule
|
Alarm / VMD / Access permission / H.264 recording / Sound detection
|
|
Input/Output
|
|
Microphone
|
Built-in microphone
|
|
General
|
|
Safety/EMC Standard
|
<Safety>
UL (UL60950-1), C-UL (CAN/CSA C22.2 No.60950-1), CE, IEC60950-1
<EMC>
FCC Part15 Class A, ICES-003 Class A, EN55022 Class B, EN55024
|
|
Power Source and Power Consumption
|
PoE (IEEE802.3af compliant) / PoE 48 V: 110 mA (Class 2 device)
|
|
Ambient Operating Temperature
|
-30 °C to +50 °C {-22 °F to 122 °F}
|
|
Ambient Operating Humidity
|
Less than 90 % (no condensation)
|
|
Water and Dust Resistance
|
IP66, IEC60529 measuring standard compatible
|
|
Shock Resistance
|
Compliant with 50 J IEC60068-2-75
|
|
Railway Application
|
EN50155, EN50121
|
|
Dimensions
|
∅109 mm x 47 (H) mm {∅4-9/32 inches x 1-27/32 inches (H)}
|
|
Mass (approx.)
|
Approx. 350 g { 0.77 lbs}
|
|
Finish
|
Main body: Aluminum die cast, light gray
Dome cover: Clear polycarbonate resin
|
