WV-NW502S

• 1,080p HD images up to 15 fps / 720p HD images up to 30 fps

•  Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous real time monitoring and high resolution recording by

• “UniPhier®”, Panasonic’s proprietary System LSI platform.

•  Full frame (Up to 30 fps) transmission at 1,280 x 960 image size (1.3 Megapixel mode)

•  Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver 128x wider dynamic range compared with conventional cameras.

•  Face Super Dynamic technology ensures clear face image.

•  Up to 3 Megapixel (2,048 x 1,536) JPEG stream (3 Megapixel mode, JPEG only)

•  H.264 and MPEG-4 are selectable for system migration.

•  High sensitivity with Day/Night function: 1.0 lx (Color), 0.08 lx (B/W) at F1.2 (Wide,1.3 Megapixel mode)

•  ABF (Auto Back Focus) ensures easy installation and stable focus in both color and B/W modes.

•  Adaptive Digital Noise Reduction: Integration of 2D-DNR and 3D-DNR ensures noise reduction in various conditions.

•  Progressive scan ensures clear images with less motion blur and no tearing even when the subject is moving.

•  Superior color reproduction by primary (RGB) color filter

•  Electronic sensitivity enhancement: Auto (Up to 16x) / OFF

•  Selectable light control modes: Outdoor / Indoor / ELC / Fixed electronic shutter Outdoor / Indoor: Electronic shutter and ALC lens iris control are automatically controlled depending on the mode and luminance level.

•  ELC: Up to 1/10,000 Electronic shutter is automatically applied for a fix iris lens.

• Fixed electronic shutter: Up to 1/10,000 fixed electronic shutter can be selectable.

•  VMD (Video Motion Detector) with 4 programmable detection areas, 15 steps sensitivity level and 10 steps detection size

•  Privacy Zone can mask up to 8 private areas, such as house windows and entrances/exits.

•  2x, 4x digital zoom controlled by browser

•  Camera title display: Up to 20 alphanumeric characters on the browser, Up to 16 alphanumeric characters with three selectable character sizes embedded in the image

•  Alarm sources including 3 terminal input, VMD and Panasonic

• alarm command can trigger actions such as SD/SDHC memory

• recording, FTP image transfer, E-mail notification, Indication on

• browser, Alarm terminal output, and Panasonic protocol output.

•  Full duplex bi-directional audio allows interactive communication between camera site and monitoring site. Optional Accessories

• Smoke Dome Cover

• WV-CW4S

• Embedded Ceiling Mount Bracket

• WV-Q169

• Standard Accessories

•  CD-ROM*1 .................................... 1 pc.

•  Installation Guide .......................... 1 pc.

•  Code Label*2 ................................. 1 pc.

• The followings are for installation.

•  2P Power Cable ............................ 1 pc.

•  4P Alarm Cable ............................. 1 pc.

•  Camera Attachment ...................... 1 pc.

•  Mount Bracket ............................... 1 pc.

•  Base Cover ................................... 1 pc.

•  Fixing Screws (M4 x 8 mm)

• (1 piece of spare screw included) .... 5 pcs.

•  Bit for tamperproof screw ............. 1 pc.

•  Butyl tape ..................................... 1 pc.

•  1 The CD-ROM contains Panasonic IP Setup Software,  viewer software "Network Camera View 4", and

• Operation Instructions (PDF).

•  2 This label may be required for network management.  The network administrator shall retain the code label.

•  JPEG image compression ratio can be changed by alarm so that higher quality image can be provided.

•  SD/SDHC Memory card slot for manual recording (H.264 / JPEG), alarm recording (H.264 / JPEG) and backup upon network failure (JPEG)

•  H.264/MPEG-4 max. bit rate/client and Total bit rate control allows flexible network traffic management. Frame rate priority mode controls bit rate and compression ratio to provide the specified frame rate.

•  Internet mode: H.264/MPEG-4 images can be transmitted over HTTP protocol.

•  Multi-language GUI and setup menu: English, French, Italian, Spanish, German, Russian (PAL) / English, French (NTSC)

•  Installation required except for English

•  IPv4/IPv6 protocol supported

•  Analog Monitor output for easier installation

•  IP66 rated water and dust resistant. Compatible with IEC60529 measurement standard.

•  Dehumidification device for use in various weather conditions

•  Vandal resistant mechanism for high reliability

•  2.8 ~ 8.0 mm, 2.8x Varifocal Auto Iris lens

•  ONVIF compliant modelSuper Dynamic HD Vandal Resistant Fixed Dome Network Camera WV-NW502STrademarks and registered trademarks

• – Microsoft, and Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.

• – UniPhier is a registered trademark of Panasonic Corporation.

• – "MEGA Super Dynamic" and "i-PRO SmartHD" logos are trademarks or registered trademarks of Panasonic Corporation.

• – ONVIF and the ONVIF logo are trademarks of ONVIF Inc.

• Important

• – Safety Precaution: Carefully read the operating instructions and installation manual before using this product.

• – Panasonic cannot be responsible for the performance of the network and/or other manufacturers' products used on the network.

•  All TV pictures are simulated.

•  Masses and dimensions are approximate.

•  Specifications are subject to change without notice.

•  These products may be subject to export control regulations.

•  All product pictures are NTSC models.
