1,080p HD images up to 15 fps / 720p HD images up to 30 fps
-
Multiple H.264 (High profile) streams and JPEG streams ensure simultaneous real time monitoring and high resolution recording by
-
“UniPhier®”, Panasonic’s proprietary System LSI platform.
-
Full frame (Up to 30 fps) transmission at 1,280 x 960 image size (1.3 Megapixel mode)
-
Super Dynamic and ABS (Adaptive Black Stretch) technologies deliver 128x wider dynamic range compared with conventional cameras.
-
Face Super Dynamic technology ensures clear face image.
-
Up to 3 Megapixel (2,048 x 1,536) JPEG stream (3 Megapixel mode, JPEG only)
-
H.264 and MPEG-4 are selectable for system migration.
-
High sensitivity with Day/Night function: 1.0 lx (Color), 0.08 lx (B/W) at F1.4 (1.3 Megapixel mode)
-
ABF (Auto Back Focus) ensures easy installation and stable focus in both color and B/W modes.
-
Adaptive Digital Noise Reduction: Integration of 2D-DNR and 3D-DNR ensures noise reduction in various conditions.
-
Progressive scan ensures clear images with less motion blur and no tearing even when the subject is moving.
-
Superior color reproduction by primary (RGB) color filter
-
Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
-
Selectable light control modes: Outdoor / Indoor / ELC / Fixed electronic shutterOutdoor / Indoor: Electronic shutter and ALC lens iris control are automatically controlled depending on the mode and luminance level.ELC: Up to 1/10,000 Electronic shutter is automatically applied for a fix iris lens. Fixed electronic shutter: Up to 1/10,000 fixed electronic shutter can be selectable.
-
VMD (Video Motion Detector) with 4 programmable detection areas, 15 steps sensitivity level and 10 steps detection size
-
Privacy Zone can mask up to 8 private areas, such as house windows and entrances/exits.
-
2x, 4x digital zoom controlled by browser
-
Camera title display: Up to 20 alphanumeric characters on the browser, Up to 16 alphanumeric characters with three selectable character sizes embedded in the imageSuper Dynamic HD Network CameraStandard Accessories
-
CD-ROM*1 .....................................1 pc.
-
Installation Guide ...........................1 pc.
-
Code Label*2 ................................. 1 pc.
-
The followings are for installation.
-
Power Cord Plug ........................... 1 pc.
-
Safety Wire Plate for Ceiling ......... 1 pc.
-
Safety Wire Lug for Wall ................ 1 pc.
-
Screws for Mounting Bracket (M2.5 x 8) ... 2 pcs.
-
*1 The CD-ROM contains Panasonic IP Setup Software,viewer software "Network Camera View 4", and Operation Instructions (PDF).
-
*2 This label may be required for network management. The network administrator shall retain the code label. Lens: optional
-
Alarm sources including 3 terminal input, VMD and Panasonic alarm command can trigger actions such as SD/SDHC memory recording, FTP image transfer, E-mail notification, Indication on browser, Alarm terminal output, and Panasonic protocol output.
-
Full duplex bi-directional audio allows interactive communication between camera site and monitoring site.
-
JPEG Image compression ratio can be changed by alarm so that higher quality image can be provided.
-
Prioritized stream control: One of the video streams can be prioritized when multiple recorders or client PCs are accessing the camera so that the recorder or the client PC can maintain the frame rate.
-
SD/SDHC Memory card slot for manual recording (H.264 / JPEG), alarm recording (H.264 / JPEG) and backup upon network failure
-
H.264/MPEG-4 max. bit rate/client and Total bit rate control allows flexible network traffic management. Frame rate priority mode controls bit rate and compression ratio to provide the specified frame rate.
-
Internet mode: H.264/MPEG-4 images can be transmitted over HTTP protocol.
-
Multi-language GUI and setup menu: English, French, Italian, Spanish, German, Russian (PAL) / English, French (NTSC)
-
* Installation required except for English
-
IPv4/IPv6 protocol supported
-
Analog Monitor output for
