Flexible system design: Analog, IP, and Hybrid analog/IP
-
Up to 64 recorders, 1,024 monitors, and 2,048 cameras (in case with encoder) can be registered.
-
Displays live images by selecting the camera number
-
Controls camera and camera preset, and Group Preset
-
Displays live Tour Sequence images on a multi-screen segment display
-
Displays live Group Sequence images on several multi-screen segment displays
-
Controls the camera and monitor by users’ preset priority
-
ON/OFF mode of the OSD on the selected monitor is possible.
-
Sequence control: Tour Sequence (128 programs, 64 steps), Group Preset (128 programs, 64 views), Group Sequence (128 programs, 64 steps)
-
Panasonic camera control: Pan/Tilt, Zoom, Focus, Brightness, Preset position call and program (up to 256), Auto mode (SEQ, SORT, AUTO PAN, PATROL), AUX 1 ~ 2
-
Flexible monitor control suitable for wall mounted monitors
-
Up to 512 users can be registered.
-
Up to 64 users can login to WV-ASC970 simultaneously.
-
Panasonic Alarm control by recorder, camera, and encoder
-
Up to 2,048 alarms and up to 1,024 event schedules can be handled.
-
User management: User authentication
-
Camera/Sequence/Monitor selection, Camera control and Recorder control can be made with the optional system controller WV-CU950.
-
Individual alarm reset and all alarm reset is possible with the system controller WV-CU950 and WV-ASM970.
-
Simultaneous multi-site operation of up to 64 satellite system using WV-ASC970
-
Redundant function by switching the operation to the other WV-ASC970 server in case of system failure
-
Easy setup by i-PRO con?guration software
