H.264, MPEG-4 and JPEG multi format
-
Up to 32 network cameras can be connected and recorded.
-
Various Recording Modes: Manual, Schedule, Event (Pre/Post), Emergency, External Timer
-
Various alarm sources include 16x Terminal inputs, 16x Camera alarms, Panasonic Alarm Protocol. Flexible alarm actions include Alarm recording, E-mail notification, Alarm message, Camera positioning, FTP image transfer, Terminal output, Panasonic alarm protocol output, Buzzer and Indicator.
-
Panasonic Camera Control: Pan/Tilt, Zoom, Focus, Brightness, Preset Position, Auto mode (depending on camera model).
-
Cameras may be assigned to one of the 8 groups to meet application requirements.
-
Flexible Playback Controls: A-B Repeat, Goto Date (Jump to specific time/date), Goto Last (Jump to 5 sec. ~ 5 min. before the record end).
-
Various Display Modes: Spot, Quad (8 patterns), Spot Sequence, Quad Sequence.
-
8 Quad screens are fully programmable. Any of the 32 cameras can be assigned to any area of the Quad screens.
-
Filtered Search: Time & Date, Event Type, Camera number, Text
-
Recorded images can be downloaded to a PC.
-
Downloadable viewer software allows playback of images downloaded from the Recorder.
-
2 setup modes available, Quick/Advanced at users’ preference.
-
2 built-in network interfaces (10Base-T/100Base-TX) for camera access and client access. Operation by one port is also possible.
-
Quick IP Setup for Panasonic i-Pro series network cameras
-
Bandwidth control: 32 k / 64 k / 128 k / 256 k / 512 k / 1,024 k / 2 M / 5 M / 10 M (bps) and unlimited
-
Up to 8 clients can monitor images and control WJ-ND300A simultaneously.
-
Image transfer to FTP server: Recorded image upon alarm and/or live image periodically
-
Performance measurement function for appropriate recording frame rate setup
-
Images recorded on the SD memory card in the i-Pro series cameras can be downloaded to the recorder manually. In addition, recordings upon network failure can be transferred automatically when the recorder is in non-recording status.
-
Alarm notification by e-mail.
-
User/Host authentication, 4 user levels and User-Camera View/Control partitioning set up for sophisticated user management of up to 32 user registrations.
-
Multi-recorder, Multi-site system can be made with optional WVASM100 i-Pro Management Software.
-
Front panel LCD screen for status display
-
HDD capacity is expandable with 4 HDD slots in the main unit and up to 6 WJ-HDE300 optional Extension Units each with 4 HDD slots.
-
Disk partitioning for flexible record management: Normal, Event, Copy
-
HDD Safety Mode to protect HDDs during the installation of WJ-ND300A
-
RAID5 capability with optional WJ-NDB301 RAID5 Boar
